License Plate Blank Production Line
Purpose
Designed for the continuous production of license plate blanks from aluminum coils, followed by retroreflective film lamination and high-precision blanking and stamping operations. The equipment ensures consistent product quality, high output, and waste minimization, making it an ideal solution for large-scale industrial manufacturing.
Parameter | Specification |
Output Rate | Up to 60 blanks/min |
Raw Material | Aluminum coil up to Ø1700 mm |
Lamination Width | Up to 305 mm |
Film Roll Length | Up to 900 m |
Press Capacity | Up to 40 t / 400 kN |
Power Supply | ~400 V |
Average Power Consumption | 20 kW |
Pneumatics | 6 bar / ~0.5 m³/min |
Process Direction | Left-to-right |
Max Aluminum Strip Width | 300 mm |
Line Dimensions (Base) | ~ 17 × 2 m |
Press Bed Area | 800 × 550 × 340 mm |
Key Advantages
- Fully automated production cycle.
- Modular architecture adaptable to government regulations and specific customer needs.
- Integrated laser marking and full GLPS software support.
- Continuous production without downtime during material changeovers.
- Industrial speed resulting in low per-unit production costs.
- Pre-stamping heating function for enhanced quality and durability.
- Versatility to produce plates in any required format.
Core Line Components
- Aluminum Strip Feeding Zone Equipped with a rotary platform for simultaneous mounting of multiple coils, allowing for rapid material replacement without stopping production.
Dimensions: 5500×1800×2000 mm;
Power: 4 kW.
- Aluminum Strip Straightening Unit (Leveler) Removes internal stresses and ensures the flatness of the aluminum strip before processing.
Dimensions: 1300×500×1000 mm;
Power: 1 kW.
- Lamination Unit Ensures Uniform application of retroreflective film with precise tension control.
Dimensions: 2000×750×1300 mm;
Power: 3 kW.
- Feeding Module Provides Stable strip advancement to the press unit.
Dimensions: 900×600×1100 mm;
Power: 3 kW.
- Laser Marking Module (Optional) Used for applying security elements and identifiers (supports up to 6 lasers).
Dimensions: 1400×600×1600 mm;
Power: up to 1.5 kW.
- Strip Pre-heating Module (Optional) Improves film adhesion and prevents cracking during the stamping process.
Dimensions: 900×600×1000 mm;
Power: 2 kW.
- Blanking and Stamping Press Performs precise cutting, corner rounding, and rim profiling.
Dimensions: 950×800×1800 mm;
Power: 5.5 kW.
- Packaging Module (Base or Optional) Automates the discharge, counting, and stacking of blanks into bundles.
Dimensions: 1200×700×850 mm;
Power: 2 kW.
